Certifications
ETL, CE
Art-Net
ArtNet, ArtNet II and ArtNet III (configurable broadcast override) | KiNET
Astronomical
Sunrise/Sunset/Twilight and Lunar phases
Audio Level
Inputs | Stereo 30-band spectrum analysis via RIO A
Automated
Moving heads, yokes or scanners
Clock
Astronomical | Battery-backed real-time clock for calendar and time-based
Conditions
Full conditional logic support
Fixture Library
LEDs in any colour configuration (RGB, RGBW, 8-bit, 16-bit, | Pharos offers a cloud library with over 13,000 fixture profiles
Inputs
Contact closure, active low, active high or 0-24V analog level via
Kinet
KiNET V1 (DMX out) and V2 (Port out); PDS/Data Enabler
Midi
MIDI Notes, SysEx or Timecode | Timecode
Pathport
DMX512 | Pathway Connectivity protocol
Pathway Connectivity Protocol
Via EXT or second port on LPC 1
RDM
Via EXT, supports discovery and addressing via Designer software
Recovery
Hardware watchdog and recessed reset
Scalable
Supports Pharos Remote Devices | Synchronises with up to 40 Pharos Controllers over network
Scripting
Lua scripting for total flexibility | Scalable
Serial Data
RS232 via EXT; RS232 or RS485 via RIO; send/receive free
Timecode
Linear Timecode via RIO A (SMPTE, Film, EBU, NTSC)
Touchscreen
4.3" capacitive touch; 480×272 24bpp; 340 cd/m2; magnetic | Buttons, sliders, colour picker, etc | IR Sensor
Wall Stations
Integrate with BPS or TPS
Web Interface
Built-in or custom designed
Data Storage
Removable SD Card (supplied)
Ethernet
UDP, TCP, Multicast; send/receive any Ethernet message
Ir Sensor
Learning IR sensor for remote control
Physical
Wall mounted
Ambient Temperature Range
0°C to 50°C (32°F to 122°F)
Humidity
10-50% relative, non-condensing
Ingress Protection
IP40
Integrate With Bps
Full conditional logic support
